AS-B
PSA Oxygen Generators
The AirSep Alpha Series Oxygen Generators produce oxygen at 95% concentration from 20 to 5,500 cubic feet hour. When electricity and a source of compressed air is supplied, these reliable machines can deliver oxygen on demand for practically any application.
Technical Specifications
Product Characteristics*
- Product Flow: 45 – 55 SCFH (1.18 – 1.45 Nm3/hr or 21 – 25 SLPM)
- Standard Product Pressure: 45 – 55 psig (310 – 379 kPa or 3.0 – 3.7 barg)
- Product Concentration: Up to 95%
- Product Dew Point: -100°F (-73°C)
Ambient Operating Conditions
- Locate the oxygen generator in a well-ventilated area that is protected from weather elements and remains between 40°F (4°C) and 104°F (40°C)
Control Power Requirements
- 120 V ~ ±10%, 50/60 Hz, 3.0 A or
- 220 V ~ ±10%, 50/60 Hz, 1.0 A
Physical Connections
- Compressed Air Inlet:¼” FNPT
- Product Gas Outlet: ¼” FNPT
Certifications and Approvals
- CAN/CSA-C22.2 No. 61010-1-12, UL 61010-1 (120 V configurations only)
PARTS & ACCESSORIES
| Model | Part # | Description |
|---|---|---|
| AS-E | AS103-1 | 120 V ±10%, 60 Hz |
| AS103-2 | 220 V ±10%, 50 Hz | |
| Required Accessories | TA150-1 | 60 Gallon Oxygen Receiver |
| KI412-1 | Accessory Kit (Interconnecting Hoses, Fittings, and Oxygen Regulator) |
